ADOR RANGER 600 Heavy Duty MIG/MAG Welding Rectifier

ADOR RANGER 600 Heavy Duty MIG/MAG Welding Rectifier

Rs. 0

Ador

WELDING MACHINE

25 In Stock

Add to wishlist

The ADOR RANGER 600 is a robust 600 Amp Thyristorized MIG/MAG Welding Rectifier engineered for heavy-duty industrial welding applications. Designed for continuous production, structural fabrication, shipbuilding, pressure vessel manufacturing, and machine building, it delivers outstanding arc stability, excellent weld quality, and dependable long-term performance.

Its hex-phase full-wave controlled rectification circuit minimizes output ripple for smooth, spatter-free welding, while advanced protection features ensure reliable operation even in demanding industrial environments. With support for carbon steel, stainless steel, and aluminium welding, the RANGER 600 is an ideal solution for professional fabrication industries.

Key Features

  • Heavy Duty 600 Amp MIG/MAG Welding Machine
  • Thyristorized Constant Voltage Power Source
  • 3 Phase 415V Industrial Input
  • Hex-Phase Full Wave Controlled Rectifier
  • Stable & Spatter-Free Arc
  • Excellent Arc Dynamics
  • Adjustable Crater Voltage & Current
  • Globule Detach Technology
  • Four Roll Wire Feeding System
  • Quick Release Wire Feed Rollers
  • Suitable for Continuous Industrial Operation
  • Forced Air Cooling
  • Over Voltage Protection
  • Under Voltage Protection
  • Single Phasing Protection
  • Overload Protection
  • Overheating Protection
  • Short Circuit Protection
  • Suitable for Carbon Steel, Stainless Steel & Aluminium
  • Compact Industrial Design

Technical Specifications

Specification Details
Brand ADOR
Model RANGER 600
Welding Process MIG / MAG
Technology Thyristorized Constant Voltage Rectifier
Input Voltage 415V AC ±10%
Phase 3 Phase
Frequency 50/60 Hz
Welding Current Range 60–600A
Open Circuit Voltage 65V DC
Duty Cycle @100% 465A
Duty Cycle @60% 600A
Cooling Forced Air
Insulation Class H
Protection Class IP23
Input Power @100% Duty 31.7 kVA
Input Power @60% Duty 40 kVA
Maximum Input Current 55A
Wire Feed Speed 1.5–18 m/min
Wire Diameter 0.8 / 1.0 / 1.2 / 1.6 mm
Wire Feeder Four Roll Drive
Wire Spool Capacity 15 kg
Wire Feeder Motor Permanent Magnet DC
Wire Feeder Voltage 42V DC
Power Source Dimensions 980 × 550 × 960 mm
Approx. Machine Weight 230 kg

Applications

  • Heavy Structural Fabrication
  • Shipbuilding
  • Pressure Vessel Manufacturing
  • Steel Fabrication Plants
  • Machine Building Industry
  • Bridge Construction
  • Railway Coach Manufacturing
  • Oil & Gas Fabrication
  • Industrial Maintenance
  • Heavy Engineering Workshops

Standard System Includes

  • RANGER 600 Power Source
  • Four Roll Wire Feeder
  • MIG/MAG Welding Torch
  • Interconnecting Cables
  • Wire Feed Unit
