Panasonic TSP-300 TIG Welding Automation Controller

Price:

Rs. 180,000

Brand: PANASONIC

Type: WELDING MACHINE

Availability: 25 In Stock

Default Title

Quantity:

The Panasonic TSP-300 is an advanced digital TIG welding automation controller designed to enhance precision, repeatability, and productivity in automated TIG welding applications. Engineered for seamless integration with Panasonic TIG welding power sources, the TSP-300 provides accurate control over welding parameters, ensuring consistent weld quality across demanding industrial production environments.

Featuring an intuitive digital interface, programmable welding sequences, and precise parameter control, the TSP-300 is ideal for automated welding systems, robotic cells, circumferential welding, pipe welding, and high-volume manufacturing. It enables manufacturers to achieve superior weld consistency while improving operational efficiency and reducing production downtime.

Key Features

Digital TIG Welding Process Controller
Compatible with Panasonic TIG Welding Systems
Programmable Welding Parameters
Precise Arc Control
Automatic Welding Sequence Management
User-Friendly Digital Interface
High Repeatability for Automated Welding
Stable Communication with Welding Power Source
Industrial-Grade Reliability
Easy Integration with Automation Systems
Continuous Production Capability
Compact and Robust Design
Low Maintenance Operation

Technical Specifications

Specification	TSP-300
Rated Input Voltage	415V ±10%
Phase / Frequency	3 Phase / 50–60 Hz
Input @ 60% Duty Cycle	16.5 kVA / 11.5 kW
Rated Output Current	5–300 A
Rated Output Voltage	16–20 V
Rated Duty Cycle	60%
Ingress Protection	IP21S
Insulation Class	H
Weight	136 kg
