ALFA ER308L Stainless Steel MIG Welding Wire

Price:

Rs. 0

Brand: ALFA

Type: MIG WELDING WIRE

Availability: 500 In Stock

Default Title

Quantity:

ALFA ER308L Stainless Steel MIG Welding Wire is a solid, smooth welding wire primarily designed for welding low-carbon 18% Cr, 10% Ni Type 304 and 304L austenitic stainless steels. The deposited weld metal offers improved resistance to general corrosion and provides radiographic-quality welds.

Product Specifications

Specification	Details
Brand	ALFA
Product Name	ALFA ER308L Stainless Steel MIG Welding Wire
Identification	ER308L
Product Type	Stainless Steel MIG Welding Wire
Classification	AWS/SFA 5.9 ER308L
BS Classification	BS 2901-90 308 S92
DIN Classification	DIN 8556-86 WSGX2 CrNi199
Welding Process	MIG / GMAW
Material	Austenitic Stainless Steel
Suitable Stainless Steel	304 / 304L
Welding Current	DC (-)
Shielding Gas	Ar + 2% O₂
Gas Flow Rate	16–21 L/min
Weld Quality	Radiographic Quality
Ferrite Number	3–10
Available Wire Sizes	0.8, 1.0, 1.2, 1.6 mm
Spool Weight	12.5 / 15.0 kg

Chemical Composition

Element	Range / Maximum
Carbon (C)	0.030% Max
Manganese (Mn)	1.0–2.5%
Silicon (Si)	0.30–0.65%
Chromium (Cr)	19.50–22.0%
Nickel (Ni)	9.0–11.0%
Copper (Cu)	0.50% Max
Molybdenum (Mo)	0.75% Max
Sulphur (S)	0.030% Max
Phosphorus (P)	0.030% Max

Mechanical Properties

Property	Value
Tensile Strength (TS)	530–650 MPa
Elongation (L=4D)	35–45%
CVN Impact at 20°C	100–140 J
CVN Impact at -100°C	40–80 J

Typical Applications

Welding Type 304 stainless steel
Welding Type 304L stainless steel
Welding Type 347 stabilized stainless steel
Welding Type 321 stabilized stainless steel
Applications where service temperature is below 400°C
Chemical process plants

Corrosion Resistance

ALFA ER308L provides good resistance to general and intergranular corrosion in oxidizing acids, along with good resistance to chloride pitting corrosion.
