Ralli Wolf RT50 TIG500IJ DC inverter welding machine. 500A output, TIG & MMA function, mobile trolley design. Ideal for heavy industrial TIG welding.

Ralli Wolf RT50 TIG 500IJ DC Inverter Welding Machine with MMA Function (500A, 415V 3-Phase)

Rs. 0

RALLI WOLF

WELDING MACHINE

20 In Stock

The Ralli Wolf RT50 (TIG 500IJ) is a high-capacity DC TIG welding machine built for heavy industrial applications requiring maximum current output alongside precise arc control. With high frequency ignition, superior arc performance, and a post-flow function, it delivers clean, stable welds while economising tungsten use through its stable output and high duty cycle. The machine also includes an MMA welding function, giving fabricators added versatility from a single unit. Mounted on a mobile trolley design with wheels for easy job-site movement, the RT50 delivers up to 500A output for the most demanding TIG welding jobs. Backed by Ralli Wolf's 60+ years of manufacturing expertise and ISO 9001:2015 certification, it's a dependable choice for heavy-duty industrial TIG welding work.

KEY FEATURES

  • High frequency ignition
  • Superior arc performance
  • Post-flow function
  • Light and compact, easy to carry and use
  • Economises tungsten use with a stable output and high duty cycle
  • Built-in MMA welding function
  • Mobile trolley design with wheels for easy transport
  • IGBT inverter technology

TECHNICAL SPECIFICATION

Specification Value
Model RT50 (TIG 500IJ)
Input Voltage AC 415V ± 15%, 3 Phase
Rated Input Current 26.2/35.0 A
Power (KVA) 25.2
No-Load Voltage 70 V
Output Current 10–500 A
Rated Output Voltage 38 V
Duty Cycle 60%
No-Load Loss 80 W
Efficiency 85%
Power Factor 0.93
Pre-Flow 2.5 Sec
Post-Flow 0–5 Sec
Arcing Way High Frequency
Net Weight 42 kg
MMA Function Available
Inverter Technology IGBT
Frequency 50/60 Hz
Standard Accessories TIG torch cable and MMA electrode holder cable

APPLICATION

  • Heavy industrial DC TIG welding for steel and stainless steel
  • MMA (Stick) welding for large-scale fabrication
  • High current welding requiring maximum penetration
  • Workshops needing mobile, trolley-mounted welding equipment
  • Jobs requiring both TIG and MMA capability from one machine
  • Applications requiring stable arc with minimal tungsten wear at high output

WHY CHOOSE THIS (Ralli Wolf RT50)

  • Delivers up to 500A DC TIG output, the highest in the Ralli Wolf TIG lineup for demanding jobs
  • Combines TIG and MMA welding functions in a single versatile unit
  • High frequency ignition ensures smooth, reliable arc starts
  • Post-flow function protects the weld pool and tungsten electrode after welding stops
  • Economises tungsten use while maintaining stable output and high duty cycle
  • Mobile trolley design with wheels makes it easy to move around large job sites
  • IGBT inverter technology ensures stable, efficient high-current performance
  • Backed by Ralli Wolf's 60+ years of trusted engineering and ISO 9001:2015 certification
