Ralli Wolf RC20 CUT200 IGBT air plasma cutting machine. 200A, cuts up to 60mm, CNC compatible, 100% duty cycle. Ideal for heavy industrial cutting.

Ralli Wolf RC20 CUT 200 Air Plasma Cutting Machine (200A, 380V 3-Phase, IGBT)

Rs. 155,000

RALLI WOLF

Plasma Cutting Machine

20 In Stock

The Ralli Wolf RC20 (CUT 200) is a high-performance air plasma cutting machine built with in-built high frequency soft-switching IGBT technology for stable, precise plasma arc combustion. It's fit for cutting a wide range of metal materials including stainless steel, alloy steel, cast iron, carbon steel, copper, aluminium, manganese, and titanium — handling cutting thicknesses from 3 to 60mm. With wide grid voltage adaptability, high reliability, and all signal outputs required by CNC control, the RC20 is well suited for automatic cutting setups in addition to manual use. Its high duty cycle allows the machine to keep working for long periods under maximum current, making it a dependable choice for heavy industrial cutting operations. Backed by Ralli Wolf's 60+ years of manufacturing expertise and ISO 9001:2015 certification, the RC20 delivers consistent, high-output performance.

KEY FEATURES

  • Fit for cutting various metal materials — stainless steel, alloy steel, cast iron, carbon steel, copper, aluminium, manganese, and titanium
  • In-built high frequency soft-switching IGBT technology
  • Wide grid voltage adaptability and high reliability with stable plasma arc combustion
  • All signal outputs required by CNC control, suitable for automatic cutting
  • High duty cycle allows long working periods under maximum current
  • Water/air cooling for the torch

TECHNICAL SPECIFICATION

Specification Value
Model RC20 (CUT 200)
Voltage 3 Phase, 380V ± 15%
Frequency 50/60 Hz
Rated Input Capacity 47 KVA
Rated Input Current 63 A
Power Factor 0.89
Rated Output Current 200 A
Rated Output Voltage 150 V
Rated Duty Cycle 100%
Output Floating Voltage 340 V
Cutting Thickness 3 to 60 mm
Output Current Range 30–200 A
Plasma Gas Usage Compressed Air
Working Gas Pressure 0.45–0.55 MPA
Efficiency 90%
Insulation Class F
Shell Protection Degree IP21S
Torch Cooling Water/Air Cooling
Arc Striking Mode High Frequency ARC Striking
Approx. Weight 75 kg
Dimensions (L x W x H) 825 x 350 x 735 mm

APPLICATION

  • Heavy industrial metal cutting
  • CNC-integrated automatic cutting systems
  • Stainless steel, alloy steel, and cast iron cutting
  • Carbon steel, copper, aluminium, manganese, and titanium cutting
  • Thick metal cutting up to 60mm
  • Continuous, high-duty-cycle cutting operations

WHY CHOOSE THIS (Ralli Wolf RC20)

  • Cuts a wide range of metals — from stainless steel and titanium to aluminium and cast iron
  • Handles cutting thickness up to 60mm, suited for heavy industrial jobs
  • 100% rated duty cycle allows continuous operation under maximum current without downtime
  • Full CNC signal output support makes it ideal for automatic cutting systems
  • High frequency soft-switching IGBT technology ensures stable plasma arc combustion
  • Wide grid voltage adaptability improves reliability across varying power conditions
  • Water/air cooled torch supports sustained high-output performance
  • Backed by Ralli Wolf's 60+ years of trusted engineering and ISO 9001:2015 certification
