Ralli Wolf RC10 CUT100 IGBT air plasma cutting machine. 100A, pilot arc, CNC interface, 400 amp MMA welding facility. Ideal for fabrication.

Ralli Wolf RC10 CUT100 Air Plasma Cutting Machine (100A, 415V 3-Phase, IGBT)

Rs. 132,500

RALLI WOLF

Plasma Cutting Machine

20 In Stock

The Ralli Wolf RC10 (CUT100) is an IGBT-based air plasma cutting machine designed to cut metals fast, cleanly, and economically. With pilot-arc technology that extends the durability of consumables, it's suitable for cutting stainless steel, copper, carbon steel, aluminium, and other metals up to 30mm thickness. The machine also includes an MMA welding facility (400 amp) alongside its plasma cutting function, giving fabricators added versatility from a single unit. With CNC interface support and an optional trolley or machine mounting type torch, the RC10 is built for both manual and automated cutting applications across general fabrication, construction, and engineering industries. Backed by Ralli Wolf's 60+ years of manufacturing expertise and ISO 9001:2015 certification, it delivers reliable, energy-efficient cutting performance.

KEY FEATURES

  • Easy to cut metals in a fast and economical way
  • Energy saving operation
  • Pilot-arc technology to extend the durability of consumables
  • Suitable for cutting stainless steel, copper, carbon steel, aluminium, and other metals
  • Optional trolley and machine mounting type torch for specific applications
  • Built-in MMA welding facility (400 amp)
  • CNC interface available for automated cutting setups

TECHNICAL SPECIFICATION

Specification Value
Product Type CUT100
Model RC10
Input Voltage AC 415V ± 15%, 3 Phase
Frequency 50/60 Hz
Rated Input Current 21 A
Power (KVA) 15.5
No-Load Voltage 320 V
Output Current Range 20–100 A
Rated Output Voltage 120 V
Duty Cycle 60%
No-Load Loss 80 W
Efficiency 85%
Power Factor 0.93
Insulation Grade F
Housing Protection Grade IP21S
Arcing Way Pilot arc transfer
Technology Required Air (IGBT)
Pressure 4.5–6 Kg/cm²
Cutting Thickness 1–30 mm
Net Weight 26.5 kg
MMA Facility Available (400 amp)
CNC Interface Available
Standard Accessories Plasma Torch, FRL Unit, Earthing Cable with Clamp

APPLICATION

  • General fabrication work
  • Construction industry cutting applications
  • Other engineering industries requiring metal cutting
  • Stainless steel, copper, carbon steel, and aluminium cutting
  • CNC-integrated automated cutting setups
  • Combined plasma cutting and MMA welding tasks

WHY CHOOSE THIS (Ralli Wolf RC10)

  • Fast, economical metal cutting across stainless steel, copper, carbon steel, and aluminium
  • Pilot-arc technology extends consumable life, reducing running costs
  • Dual functionality with built-in MMA welding facility (400 amp) in the same unit — higher capacity than the RC80's 250 amp
  • Handles cutting thickness up to 30mm for a range of fabrication needs
  • CNC interface support enables integration with automated cutting systems
  • Optional trolley and machine mounting torch options add flexibility for different setups
  • Comes with standard accessories — Plasma Torch, FRL Unit, and Earthing Cable with Clamp
  • Backed by Ralli Wolf's 60+ years of trusted engineering and ISO 9001:2015 certification
