Panasonic YD-400AT3DJR 400A DC Inverter MMA Welding Machine

Price:

Rs. 45,740

Brand: PANASONIC

Type: WELDING MACHINE

Availability: 25 In Stock

Default Title

Quantity:

The Panasonic YD-400AT3DJR is a premium industrial 400A DC Inverter MMA (Stick) Welding Machine engineered for demanding fabrication, construction, heavy engineering, repair, and maintenance applications. Built with advanced IGBT inverter technology, it delivers exceptional arc stability, high efficiency, and reliable performance even under continuous heavy-duty operation.

Designed for professional welders, the YD-400AT3DJR features an Amp Meter display, adjustable Hot Start and Arc Force controls, and an integrated Voltage Reduction Device (VRD) to enhance operator safety. Its rugged IP23-rated enclosure, forced-air cooling system, and compliance with international welding standards make it a dependable choice for industrial environments

Key Features

400A Industrial DC MMA (Stick) Welding Machine
Advanced IGBT Inverter Technology
Wide Welding Current Range: 20–410A
Digital Amp Meter Display
Adjustable Hot Start Function
Adjustable Arc Force Control
Built-in Voltage Reduction Device (VRD)
Stable Arc with Low Spatter
High Power Factor (>0.9)
Forced Air Cooling System
IP23 Protection Class
Class H Insulation
Heavy-Duty Industrial Design
Manufactured to IEC 60974-1 Standards

Technical Specifications

Specification	Details
Model	Panasonic YD-400AT3DJR
Welding Process	MMA (Stick Welding)
Input Voltage	415V ±20%
Input Phase	3 Phase
Frequency	50/60 Hz
Power Control	IGBT Inverter
Rated Input Capacity	17.6 kVA / 16.7 kW
Welding Current Range	20–410 A
Rated Output Current (60% Duty Cycle)	400 A
Rated Output Current (100% Duty Cycle)	310 A
Rated Output Voltage	36 V
VRD Output Voltage	<13V DC
Duty Cycle	60% @ 400A
Power Factor	>0.9
Cooling Method	Forced Air Cooling
Protection Class	IP23
Insulation Class	H
Operating Temperature	-10°C to +50°C
Dimensions	550 × 330 × 600 mm
Weight	50 kg
