Panasonic YD-250KR2 KR2 Series MIG/MAG Welding Machine

Panasonic YD-250KR2 KR2 Series MIG/MAG Welding Machine

Rs. 0

PANASONIC

WELDING MACHINE

25 In Stock

The Panasonic YD-250KR2 from the renowned KR2 Series is a fully thyristorised MIG/MAG welding machine engineered for high-quality industrial welding. Designed for continuous production environments, it delivers ripple-free DC output, exceptional arc stability, and superior welding performance.

Featuring Panasonic's advanced synergic control, high-speed wire feeding, and robust wire feeder system, the KR2 Series is ideal for automotive manufacturing, fabrication, engineering workshops, and heavy industrial applications. With over 500,000 KR Series machines sold globally, it has earned a reputation for reliability and consistent performance.

Key Features

  • Fully Thyristorised MIG/MAG Welding System
  • Ripple-Free DC Output for Superior Weld Quality
  • Synergic (Unified) Welding Mode
  • Adjustable Burn-Back Time
  • Secondary Short Circuit Protection
  • Adjustable Arc Sensitivity
  • Crater Current & Voltage Control
  • Gas Check Switch
  • Solid / FCW Wire Selection
  • Ergonomic MIG Torch
  • Printed Circuit Wire Feeder Motor
  • Wire Feed Speed up to 20.1 m/min
  • Standard 2-Roll Drive (Optional 4-Roll Drive)
  • Euro Connector MIG Torch Available
  • Wire Feeder Available in 1.8m, 5m, 10m, 15m & 20m Lengths
  • Heavy Duty Industrial Construction
  • Made in India

Technical Specifications – Panasonic YD-250KR2

Specification YD-250KR2
Rated Input Voltage 415V ±10%
Phase / Frequency 3 Phase / 50–60 Hz
Max. Input @ 60% Duty Cycle 9.5 kVA / 7.9 kW
Rated Current Range 50–250 A
Rated Output Voltage 15–27 V
Welding Current @ 60% Duty Cycle 250 A
Welding Current @ 100% Duty Cycle 194 A
Dimensions (L × W × H) 376 × 675 × 747 mm
Weight 94 kg

Wire Feeder Specifications

Specification Value
Rated Welding Current 250 A
Applicable Wire Diameter 0.8, 1.0, 1.2 mm
Weight 10.5 kg
Standard Wire Feeder Cable Length 1.8 m, 5 m, 10 m, 15 m & 20 m

Welding Torch (YT-35CS4)

Specification Value
Rated Welding Current 350 A
Duty Cycle (10 Min.) 350 A @ 60% (CO₂)
350 A @ 35% (CO₂ + Ar)
Continuous Duty 270 A @ 100% (CO₂)
200 A @ 100% (CO₂ + Ar)
Applicable Wire Diameter 0.8, 1.0, 1.2 mm
Cable Length 3 m
Weight (Including Cable) 2.8 kg

Applications

  • Automobile Manufacturing
  • Heavy Fabrication
  • Structural Steel
  • Engineering Industries
  • Sheet Metal Fabrication
  • Industrial Production Lines
  • General Manufacturing
  • Maintenance Workshops

Why Choose Panasonic KR2 Series?

  • Proven industrial reliability
  • Over 500,000 KR Series machines sold worldwide
  • Excellent arc stability
  • Superior welding quality
  • Durable wire feeder system
  • Low maintenance
  • Designed for continuous production
