ADOR CHAMPMIG 300 Inverter MIG/MMA Welding Machine

Price:

Rs. 0

Brand: Ador

Type: WELDING MACHINE

Availability: 25 In Stock

Quantity:

ADOR CHAMPMIG 300 Inverter MIG/MMA Welding Machine

The ADOR CHAMPMIG 300 is a professional-grade 3-phase inverter-based MIG/MMA welding machine designed for industrial fabrication, manufacturing, maintenance, and heavy engineering applications. Built with advanced high-frequency inverter technology, it delivers stable arc performance, high efficiency, and excellent power factor for demanding welding jobs.

This dual-process CC/CV welding machine supports both MIG (GMAW) and MMA (Stick) welding, making it a versatile solution for fabrication workshops and production environments. The user-friendly digital control panel features a 7-segment LED display with multifunction controls for precise adjustment of welding voltage, wire feed speed, and welding parameters.

The CHAMPMIG 300 also includes Anti-Stick protection in MMA mode, 2T/4T trigger selection, crater adjustment, burn-back control, gas pre/post flow settings, and 10 memory channels for quick recall of frequently used welding parameters. An optional remote control unit enables convenient adjustment of voltage and wire feed speed from up to 10 meters away.

Designed with IP23S protection, Class H insulation, and forced-air cooling, the CHAMPMIG 300 offers dependable performance even in demanding industrial environments.

Key Features

Dual Process MIG & MMA Welding
Advanced High-Frequency Inverter Technology
CC/CV Output Characteristics
Digital LED Display with Multifunction Controls
Stable Arc & Smooth Welding Performance
Anti-Stick Function in MMA Mode
2T / 4T Trigger Selection
Adjustable Gas Pre-Flow & Post-Flow
Burn-Back Control
Crater Voltage & Current Adjustment
Supports 0.8 / 1.0 / 1.2 mm Welding Wire
10 Memory Save & Recall Functions
Optional 10 Meter Remote Control
High Efficiency up to 85%
Forced Air Cooling
IP23S Protection
Class H Insulation
Ideal for Industrial Fabrication & Heavy Welding Applications

Technical Specifications

Specification	Details
Model	ADOR CHAMPMIG 300
Welding Process	MIG / MMA
Technology	Inverter
Input Voltage	415V AC (+15% / -10%)
Phase	3 Phase
Frequency	50/60 Hz
Output Type	CC/CV
MIG Current Range	10–300 A
MMA Current Range	50–250 A
MIG Voltage Range	14–40 V
Open Circuit Voltage	65V (MIG), 88V (MMA)
Wire Sizes	0.8 / 1.0 / 1.2 mm
Duty Cycle (40°C)	195A @ 100%
Efficiency	Up to 85%
Protection Class	IP23S
Cooling	Forced Air
Insulation Class	H
Dimensions	575 × 225 × 450 mm
Weight	Approx. 28 kg
